Compatibility:
KT and DM Stainless Steel Enclosures

Description:
Used for wall mounting. It can be installed both in vertical and horizontal positions. Allows enclosure installation by hanging onto pre-installed bolts on the wall. Compliant with IEC 62208 and UL508A standards.

Load capacity:
2800 N per bracket in vertical mounting, 1500 N per bracket in horizontal mounting.

Relevant Size:
Compatible with all enclosure sizes

Material:
AISI 316 (1.4404)

Surface Treatment:
Untreated Surface

Product Content:
4 wall brackets and enclosure mounting bolts

Note:
Due to IP protection requirements, stainless steel KT and DM enclosures are not supplied with wall-mounting holes. Marking points on the back of the enclosure may be drilled for mounting. Welding the brackets to the enclosure is another applicable method.
