• Suitable for single-pole miniature circuit breaker (MCB) and molded case circuit breaker (MCCB) direct connections and multi outputs.
• Suitable for DIN rail or mounting plate installation.
• Input connection via copper; output connections via cable lug (ferrule) method.
• Available in 80A – 125A – 160A current ratings.
• Compliant with IEC 60947-7-1, IEC 60947-1, IEC 61439-1 standards.
• Operational Voltage (Ue): 415V AC
• Insulation Voltage (Ui): 690V AC / 690V DC
• Impulse Withstand Voltage (Uimp): 6kV
• Short-Circuit Withstand (Icc or Icw): See “More Information” for each product.
• Peak Short-Circuit Withstand (Ipk): Not available
• Flame retardancy rated V0 according to UL 94 standard.
• Halogen-free.

Material:
Active Conductors:
Tin-plated brass

Plastic Components:
Glass-fiber reinforced polyamide (PA 6.6)
